Entdecken Sie PXN Direct Drive Wheel Bases für 6Nm und 10Nm Leistung

Versorgen Sie Ihr Sim-Racing-Setup mit einer PXN Wheelbase mit Direct-Drive-Servomotor-Architektur, die stabiles Drehmoment und präzises Lenkverhalten für kompetitive Rennbedingungen liefert.
Filter Ansicht als:

DD Wheel Bases für Direct Drive Racing Performance


PXN DD Wheel Bases liefern präzises Force Feedback mit gleichmäßiger Drehmomentabgabe und robuster Konstruktion, wodurch eine stabile Lenkpräzision und eine reibungslose Steuerung unter anspruchsvollen Rennbedingungen gewährleistet und das Fahrgefühl insgesamt verbessert wird.

Aufgebaut auf einer Direct-Drive-Servomotor-Architektur, unterstützen diese Wheelbases Sim-Racing-Setups mit starker Kompatibilität für Schnellverschlusslenkräder und PC-Systeme. Sie bieten eine stabile Steuerung und variierende Drehmomentstufen über verschiedene Modelle hinweg, um unterschiedlichen Rennstilen und Setup-Präferenzen gerecht zu werden.

Stöbern Sie durch die PXN Direct Drive Wheel Bases, um Leistungsoptionen zu vergleichen und ein Setup auszuwählen, das Ihren Anforderungen an die Rennsteuerung entspricht.

Frequently Asked Questions

How to set up the PXN VD series wheel bases and connect to the PC?

Follow these steps to install and connect your PXN VD series wheel bases:

1. Install the mounting clamp

  • Place panel B on the edge of your desk and secure it with the clamp.
  • Align panel A with the mounting holes on the PXN VD series wheel base and tighten the screws.
  • Position the assembled base plate at the center of panel B.
  • Align the rear and front screw holes, select the preferred angle adjustment position, and tighten the screws to secure the base.

2. Install the steering wheel
Attach the wheel to the wheel base after the base installation is complete.

3. Connect the wheel base to the PC

  • Connect the power cable to the power adapter and plug it into the DC IN port on the VD series wheel base.
  • Connect the USB-C end of the computer connection cable to the PC port on the wheelbase, then connect the USB end to the computer.
  • Press the white power button on the back of the base to turn it on.

4. Test the connection
The steering wheel will automatically self-calibrate and return to the center position after powering on.
Once connected, open Game Controllers in Windows and test the buttons to confirm that the device is working properly.

How to fix weak force feedback or a shifting center position on VD series wheelbases?

If you experience weak force feedback or an unstable center position, follow these troubleshooting steps:

1. Reset the wheelbase settings to default
Use the shortcut keys for your steering wheel rim:
W AS: Press and hold N + Y for 5 seconds.
W DS R2: Press and hold SHARE + Y for 5 seconds.
W CS R2: Press and hold DRS + Y for 5 seconds.

2. Recalibrate the steering center position
Open PXN SimRacing software and complete the steering wheel center calibration.

3. Calibrate the electrical angle
Disconnect the power cable.
Connect a USB-to-Type-C cable between the wheelbase PC port and USB port.
Reconnect the power cable and press the power button to start calibration.

4. Update the wheelbase firmware
Ensure the wheelbase firmware is updated to the latest version for optimal performance.

Do I need a table to use PXN direct drive wheel bases?

No. A table is not required to use PXN direct drive wheel bases. They can be installed on different sim racing setups, including desks with a compatible mounting clamp or dedicated racing cockpits with suitable mounting points.

For desktop setups, use a compatible PXN table clamp to secure the wheel base. For cockpit installations, mount the wheel base directly using the appropriate mounting hardware.
